2022 Harley-Davidson® SOFTAIL LOW RIDER S Gunship Gray- UH67219
Get in Touch
Description
2022 Harley-Davidson® SOFTAIL LOW RIDER S Gunship Gray
Info
Industry
Powersports
Make
Harley-Davidson®
Model
SOFTAIL LOW RIDER S
Trim
Gunship Gray
Year
2022
Msrp
14998
Price
14998
Stock Number
UH67219
Category
MOTORCYCLE
Subcategory
MOTORCYCLE
Condition
Pre-Owned
Location
Karl Malone Powersports Provo
Fuel Type
Gas
VIN
1HD1YWZ21NB067219
Odometer
10374
Specifications
Cylinders
2
Fuel Capacity
5
GVWR
1160
Seats
1
Enginee
1,923 cc (117 cu in)
Horsepower
103 HP (77 kW) @ 4,750 rpm
Engine Type
Milwaukee-Eight® 117, V-Twin (Pushrod-operated, overhead valves; 4 valves per cylinder)
Torque
125 ft-lb (169 Nm) @ 3,500 rpm
Compression Ratio
10.2:1
Family
Cruiser / Softail®
Upholstery
Vinyl solo seat skin
Engine Cooling
Precision Air/Oil-Cooled
Exhaust
2-into-2 offset shotgun; catalyst in muffler
Transmission
6-speed Cruise Drive manual
Drive Train
Belt final drive, 34/46 ratio
Chain
Primary chain drive (1.35:1 ratio)
Clutch
Mechanical, wet multi-plate with diaphragm spring in oil bath
Bore x Stroke
4.075 in. x 4.5 in. (103.5 mm x 114.3 mm)
Primary Drive
Chain
Frame
Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions
Rear Subframe
Aluminum forged fender supports
Rake
28° (Steering head angle)
Trail
5.7 in. (145 mm)
Front Fork
Single cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring
Right
31.3°
Left
31.3°
Swingarm
Mild steel, tubular sections, stamped x-member, forged axle junctions
Suspension (Front)
Single cartridge 43 mm inverted fork (5.0 in. / 130 mm travel)
Suspension (Rear)
Hidden, free piston, coil-over monoshock; 56 mm stroke; hydraulic preload adjustment
Front Shocks
Inverted internal single cartridge fork springs
Rear Shocks
Hidden coil-over monoshock (4.4 in. / 112 mm wheel travel)
Fuel Type
Premium Unleaded (91 octane or higher)
Fuel System
Electronic Sequential Port Fuel Injection (ESPFI)
Fuel Efficiency
47 mpg (5 L/100 km) estimated combined
Lubrication System
Dry sump
Oil Type
Harley-Davidson Genuine H-D 360 Motorcycle Oil (20W50)
Oil Capacity
5.0 qt. (4.7 L) with filter
Ground Clearance
5.7 in. (145 mm) static
Height
47.0 in
Length
93.1 in
Width
34.3 in
Seat Height
27.0 in. (686 mm) laden / 28.0 in. (710 mm) unladen
Weight (Dry)
650 lbs. (295 kg) as shipped
Weight (Wet)
679 lbs. (308 kg) in running order
Max Payload
481 lbs. (218 kg)
Front Brake
Dual 300 mm fixed rotors with 4-piston fixed calipers
Rear Brake
Single 292 mm floating rotor with 2-piston floating caliper
Front Caliper
4-piston fixed
Rear Caliper
2-piston floating
Wheels
Dark bronze, Radiate cast aluminum wheels
Wheelbase
63.6 in
Front Wheel (Dia)
19 in
Rear Wheel (Dia)
16 in
Front Tire
Michelin® Scorcher® "31" 110/90B19 62H BW
Front Tire Width
110 mm
Rear Tire
Michelin® Scorcher® "31" 180/70B16 77H BW
Rear Tire Width
180 mm
Tire Ply Rating
Bias ply
Silencer
Catalyst built into muffler walls
Instrumentation
4-inch analog tachometer with digital speedometer, gear indicator, odometer, fuel level, clock, trip meters, and range indication
Speedometer
Digital display readout
Ignition/Starter
Keyless ignition with Fob / 1.6 kW electric starter motor with solenoid shift
Lighting
All-LED headlamp (low beam, high beam, signature position lamp), LED Zeppelin tail/stop lamp, incandescent bullet turn signals
Headlight(s)
All-LED low/high beam with signature position ring
Electrical System
Three-phase, 42 Amp charging system (546 Watts max power @ 13V, 2000 rpm)
Battery
Sealed, maintenance-free AGM, 12V, 17.5Ah, 310 CCA
Alternator
42 Amp stator and rotor setup
Fairing
Color-matched mini front headlight speed cowl
Front Fender
Sport style trimmed front fender
Rear Fender
Bobbed rear custom style fender
Floor boards
Mid-mount footpegs for operator
Active Descent Control
Rear wheel deceleration control / Engine compression braking
Power Outlet
USB A-Type port integrated into frame; output 5V at 2.4A
Security
Smart Security System with proximity-based hands-free security fob
Warranty
24 months, unlimited mileage limited warranty
